John Deere 6125M Mechanical
Chassis:
4×2 2WD
4×4 MFWD 4WD
Differential lock:
Electro-hydraulic rear
limit-slip front (4WD)
Steering:
hydrostatic power
Brakes:
hydraulic wet disc
Cab:
Two-post foldable ROPS. Cab optional with air-conditioning. GreenStar (optional)
AutoTrac (optional)
Transmissions:
12-speed fully synchronized
16-speed partial power shift
24-speed partial power shift
Fuel:
58 gal 219.5 L
Hydraulic system:
13.7 gal 51.9 L
Type:
open center pressure compensated
closed center load sensing pressure and flow compensated (optional)
Capacity:
13.7 gal 51.9 L
Pressure:
2900 psi 200.0 bar
Rear valves:
1 to 3
Mid valves:
2 or 3 (optional)
Pump flow:
21.1 gpm 79.9 lpm
30 gpm 113.6 lpm (optional)
SCV flow:
21.1 gpm 79.9 lpm
Rear Type:
II/IIIN
Control:
electrohydraulic load sensing
Rear lift (at 24″/610mm):
5154 lbs 2337 kg
6247 lbs 2833 kg (optional)
Drawbar:
Cat. II
Rear PTO:
independent
Rear RPM:
540/1000 (1.375)
Engine RPM:
540@19321000@1932
John Deere PowerTech PVX
variable geometry turbocharger with intercooler diesel
4-cylinder
liquid-cooled
Displacement:
276 ci 4.5 L
Bore/Stroke:
4.19×5.00 inches 106 x 127 mm
Emissions:
Interim Tier IV
Emission control:
cooled exhaust gas recirculation
Rated Power (EC 97/98):
125 hp 93.2 kW
Maximum Power (EC 97/68):
130 hp 96.9 kW
Fuel system:
high pressure common rail
Compression:
16.1:1
Rated RPM:
2100
Torque:
415 lb-ft 562.7 Nm
Torque RPM:
1600
Starter:
electric
Starter volts:
12
Oil capacity:
16.9 qts 16.0 L
Coolant capacity:
23.3 qts 22.1 L
Transmission:
SyncroPlus
Type:
fully synchronized
Gears:
12 forward and 4 reverse
Clutch:
wet disc
Wheelbase:
101.6 inches 258 cm
Weight:
11519 lbs 5225 kg
Max weight:
19180 lbs 8700 kg
Clearance (front axle):
20.47 inches 51 cm (4WD)
Rear axle:
Flange
Rear axle:
Bar: 3.1 by 100.6 inches 78 by 2555 mm
Front tread:
60.4 to 80.4 inches 153 to 204 cm (2WD)
John Deere 6125M Tests
OCED Tractor Test 2078
| OCED Tractor Test 2078 | |
| Diesel 24-speed PowrQuad Plus 4WDOctober 22 – 30, 2013Link: OCED Tractor Test 2078 file | |
| PTO performance | |
| Max power: | 114.88 hp 85.7 kW |
| Fuel use: | 6.7 gal/hour 25.4 l/hour |
| Power at rated engine speed: | 2101 hp 1566.7 kW |
| Fuel use: | 4710.8 gal/hour 17830.4 l/hour |
| Power at rated PTO speed: | 114.39 hp 85.3 kW |
| Fuel use: | 6.9 gal/hour 26.1 l/hour |
| Drawbar performance | |
| Max power: | 98.31 hp 73.3 kW |
| Fuel use: | 6.7 gal/hour 25.4 l/hour |
| Max pull: | 10828 lbs 4911 kg |
FAQ
Is John Deere 6125M a good tractor?
The John Deere 6125M is one of the great tractors in the John Deere stable, and it has earned John Deere a fantastic reputation.
How much oil does a John Deere 6125M take?
Check out the John Deere 6125M oil capacity and oil type in the engine specs section as it may vary across the engines. Keep in mind, that older models might have their oil capacity increased over time. You may compare between the early and late oil capacity.
Do tractors have VIN numbers?
Every tractor has a VIN number. The number is usually engraved below the driver’s seat. Tractor manufacturers put the number in different places on the tractor body.
What was the last year John Deere made the 6115M
The John Deere 6125M was an agricultural tractor model made from 2013 – 2015
Высокая эффективность привыполнении любых задач
Теперь Ваш трактор John Deere серии 6M способен осилить задание наивысшей сложности. Широкий диапазон функций позволяет ему стать Вашим безотказным помощником для выполнения самых разнообразных операций. Независимо от того, занимаетесь ли Вы растениеводством, животноводством или руководите специализированным хозяйством, Вы мгновенно оцените многофункциональность этих машин. Тракторы серии 6М в равной мере успешно используются как в поле, например, для возделывания почвы, ухода за посевами, возделывания пастбищ, так и в хозяйстве — для выполнения погрузочно-разгрузочных операций, а также транспортных работ.
Тракторы John Deere серии 6M стали еще более мощными, универсальными и простыми в эксплуатации и обслуживании.
Maintenance
Regular maintenance of the John Deere 6125M is crucial to ensure its optimal performance and reliability. Here are some important points to pay attention to during maintenance:
- Regular checking and cleaning of the air filter to ensure optimal air supply to the engine.
- Checking the oil level and regular oil changes according to the manufacturer’s specifications.
- Check and tighten screws and fasteners to avoid loose parts.
- Checking the coolant level and the cooling system to avoid overheating.
- Check tire pressures for optimal traction and tire longevity.
It is recommended to carry out the maintenance work according to the manufacturer’s instructions and to carry out regular inspections in order to identify and rectify possible problems at an early stage. Proper maintenance can maximize the life of your John Deere 6125M and ensure reliable performance.
Prices for spare parts
When servicing a tractor like the John Deere 6125M, it is important to keep an eye on the cost of replacement parts. Here are some sample prices for common replacement parts for this model:
| spare part | Price |
|---|---|
| Air filter | 50 € |
| Oil filter | €20 |
| Spark plugs | 15 € (each) |
| water pump | €200 |
| V-belt | €30 |
Prices may vary by retailer and region. It is advisable to compare prices and choose quality parts to ensure optimal performance and reliability from your tractor.
Conclusion
The John Deere 6125M is a powerful tractor that efficiently supports your agricultural activities. With impressive engine power, robust construction and advanced features, it offers optimal performance and reliability. The tractor is easy to maintain and offers a comfortable cab for long working days. Carefully compare specifications, costs and operating experience to determine if the John Deere 6125M is the right choice for your farming operation.
Valtra n 103 Technical Specifications
Valtra A-Series Technical Specifications
Spécifications John Deere 6125M
Especificaciones de John Deere 6125M
John Deere 6125M Specificații
Dane techniczne John Deere 6125M
Advantages and disadvantages
Like every tractor, the John Deere 6125M has advantages and disadvantages. Here are some important advantages and disadvantages of this model:
Benefits
- Powerful engine for demanding tasks.
- Robust gear system for precise shifting.
- Efficient hydraulic power and lifting capacity.
- Spacious and comfortable cabin for long-lasting comfort.
- High-quality tires for optimum traction and off-road capability.
- Reliable performance and easy maintenance.
- Attractive value for money compared to other models.
Disadvantages
- Weight can limit maneuverability in tight areas.
- Higher acquisition costs compared to smaller models.
- Fuel consumption can be higher during intensive work.
It is important to weigh the pros and cons of the John Deere 6125M and consider your specific needs and priorities before making a purchasing decision.
John Deere 6125M Production
Manufacturer:
John Deere
Type:
Utility tractor
Factory:
Mannheim, Baden-Wurttemberg, Germany
Original price:
$74,324 (2014 SyncroPlus ROPS 2WD )
Original price:
$101,397 (2014 AutoQuad Cab 4WD )
Engine:
Engine (gross):
125 hp 93.2 kW
Engine (max):
130 hp 96.9 kW
PTO (claimed):
102 hp 76.1 kW
Drawbar (tested):
98.31 hp 73.3 kW
PTO (tested):
2101 hp 1566.7 kW
Ground:
negative
Charging system:
alternator
Charging amps:
90
150 (optional)
Charging volts:
14
Battery volts:
12
Chassis:
4×2 2WD
4×4 MFWD 4WD
Differential lock:
Electro-hydraulic rear
limit-slip front (4WD)
Steering:
hydrostatic power
Brakes:
hydraulic wet disc
Cab:
Two-post foldable ROPS. Cab optional with air-conditioning. GreenStar (optional)
AutoTrac (optional)
Transmissions:
12-speed fully synchronized
16-speed partial power shift
24-speed partial power shift
Fuel:
58 gal 219.5 L
Hydraulic system:
13.7 gal 51.9 L
Type:
open center pressure compensated
closed center load sensing pressure and flow compensated (optional)
Capacity:
13.7 gal 51.9 L
Pressure:
2900 psi 200.0 bar
Rear valves:
1 to 3
Mid valves:
2 or 3 (optional)
Pump flow:
21.1 gpm 79.9 lpm
30 gpm 113.6 lpm (optional)
SCV flow:
21.1 gpm 79.9 lpm
Rear Type:
II/IIIN
Control:
electrohydraulic load sensing
Rear lift (at 24″/610mm):
5154 lbs 2337 kg
6247 lbs 2833 kg (optional)
Drawbar:
Cat. II
Rear PTO:
independent
Rear RPM:
540/1000 (1.375)
Engine RPM:
540@19321000@1932
John Deere PowerTech PVX
variable geometry turbocharger with intercooler diesel
4-cylinder
liquid-cooled
Displacement:
276 ci 4.5 L
Bore/Stroke:
4.19×5.00 inches 106 x 127 mm
Emissions:
Interim Tier IV
Emission control:
cooled exhaust gas recirculation
Rated Power (EC 97/98):
125 hp 93.2 kW
Maximum Power (EC 97/68):
130 hp 96.9 kW
Fuel system:
high pressure common rail
Compression:
16.1:1
Rated RPM:
2100
Torque:
415 lb-ft 562.7 Nm
Torque RPM:
1600
Starter:
electric
Starter volts:
12
Oil capacity:
16.9 qts 16.0 L
Coolant capacity:
23.3 qts 22.1 L
Transmission:
SyncroPlus
Type:
fully synchronized
Gears:
12 forward and 4 reverse
Clutch:
wet disc
Wheelbase:
101.6 inches 258 cm
Weight:
11519 lbs 5225 kg
Max weight:
19180 lbs 8700 kg
Clearance (front axle):
20.47 inches 51 cm (4WD)
Rear axle:
Flange
Rear axle:
Bar: 3.1 by 100.6 inches 78 by 2555 mm
Front tread:
60.4 to 80.4 inches 153 to 204 cm (2WD)
John Deere 6125M Tests
OCED Tractor Test 2078
| OCED Tractor Test 2078 | |
| Diesel 24-speed PowrQuad Plus 4WDOctober 22 – 30, 2013Link: OCED Tractor Test 2078 file | |
| PTO performance | |
| Max power: | 114.88 hp 85.7 kW |
| Fuel use: | 6.7 gal/hour 25.4 l/hour |
| Power at rated engine speed: | 2101 hp 1566.7 kW |
| Fuel use: | 4710.8 gal/hour 17830.4 l/hour |
| Power at rated PTO speed: | 114.39 hp 85.3 kW |
| Fuel use: | 6.9 gal/hour 26.1 l/hour |
| Drawbar performance | |
| Max power: | 98.31 hp 73.3 kW |
| Fuel use: | 6.7 gal/hour 25.4 l/hour |
| Max pull: | 10828 lbs 4911 kg |
FAQ
Is John Deere 6125M a good tractor?
The John Deere 6125M is one of the great tractors in the John Deere stable, and it has earned John Deere a fantastic reputation.
How much oil does a John Deere 6125M take?
Check out the John Deere 6125M oil capacity and oil type in the engine specs section as it may vary across the engines. Keep in mind, that older models might have their oil capacity increased over time. You may compare between the early and late oil capacity.
Do tractors have VIN numbers?
Every tractor has a VIN number. The number is usually engraved below the driver’s seat. Tractor manufacturers put the number in different places on the tractor body.
What was the last year John Deere made the 6115M
The John Deere 6125M was an agricultural tractor model made from 2013 – 2015
Серия 8R
Если предыдущие образцы относились к средним, то трактор John Deere 8R принадлежит к классу тяжелой сельхозтехники. Эти машины снабжаются множеством электронных узлов, помогающих в управлении трактором, мощные моторы и различные трансмиссии, в зависимости от модели. Машины производятся в колесном исполнении (R) и в гусеничном (маркируется как RT).
8R работают на 9-литровом дизельном агрегате рядного исполнения с 6 цилиндрами и жидкостным охлаждением последних. Общая система охлаждения – воздушная, принудительная (турбонаддув).
В базовой комплектации ко всем моделям идет задний ВОМ, доступна также и установка переднего. Вместе с задней и (опциональной) передней навеской это позволяет использовать множество вариантов дополнительного оборудования и делает трактора многофункциональными.
| Модель | 8270R | 8295R | 8320R | 8335R | 8345R | 8370R | 8320 RT | 8345RT | 8370RT |
| Силовая установка | Дизель PowerTech PSX 9 л. | ||||||||
| Мощность (номинальная) | 270 л.с. | 295 л.с. | 320 л.с. | 335 л.с. | 345 л.с. | 370 л.с. | 320 л.с. | 345 л.с. | 370 л.с. |
| Крутящий момент (на 1500 об.) | 1264 Нм | 1381 Нм | 1498 Нм | 1569 Нм | 1615 Нм | 1732 Нм | 1498 Нм | 1615 Нм | 1732 Нм |
| Грузоподъемность | 6.15 т. (средняя) | До 11.87 т, в зависимости от опций навески | |||||||
| Тип передвижения | Колеса | Гусеницы | |||||||
| Колесная база | 3.08 м | 2.515 м | |||||||
| Высота, м | 3.299/3.353/3.484 (в зависимости от шин) | 3494 | |||||||
| Длина, м | 6.224 (без балластных грузов на передней опоре)/6.591 (с грузами) | 6.47 | |||||||
| Ширина | 2.6 м | 2.552/3.05 (по заднему мосту) | |||||||
| Клиренс | 68.6 см. | 39.2 см. | |||||||
| Масса | 11.84 т. | 16.42 т. |
Функциональность без лишней сложности
Проверенные преимущества и возможности серии 6M определили ее историю успеха. И теперь, благодаря повышенной мощности, большему комфорту и удобству в управлении, открывается следующая глава в этой истории. Трактор John Deere 6195M — это новая флагманская модель с номинальной мощностью 195 л.с. (97/68 ЕС).
Новая серия 6M создана на основе признанного полнорамного дизайна John Deere, который обеспечивает наивысшую прочность конструкции и более низкий уровень вибраций. Гидравлическая система была усовершенствована, чтобы гарантировать повышенную грузоподъемность, необходимую для работы с более габаритным и тяжелым рабочим оборудованием. Эти нововведения, безусловно, положительно отразятся на Вашей производительности.
Operating experience
As a farmer, I have personally used the John Deere 6125M on my farm and have been impressed with its performance and reliability. The tractor offers an impressive 125 hp and can handle a wide range of tasks. The engine runs quietly and efficiently, while the transmission system allows for smooth shifting. The cab provides a comfortable workspace that reduces fatigue and increases productivity. The tractor’s hydraulic power and lift capacity helped me move heavy loads with ease.
In terms of maintenance, the John Deere 6125M was easy to handle. Regular maintenance and inspection of key components have ensured reliable performance and minimal downtime. The replacement parts were readily available and reasonably priced.
Overall, I am very satisfied with my operating experience with the John Deere 6125M. This tractor has efficiently supported my farming activities and exceeded my expectations.
